Product details of the group 27 deep cycle battery
Product Introduction
The whole production process of group 27 deep cycle battery is completed by using sophisticated and modern machines in adherence to the industry set standards. The product is in compliance with some of the toughest quality standards across the world. has obtained fame and reputation in group 27 deep cycle battery market.
Part Number |
GTEM-24V3200-E |
3.2kWh |
|
Nominal Voltage |
24Vdc |
Maximum Charge Voltage |
29Vdc |
Discharge Cut-off Voltage |
20Vdc |
ESR/AC @1KHz 50% SOC |
<15Ω |
Max. Continuous Charge Current |
40A |
Max. Continuous Discharge Current |
40A |
Cells Self-discharge Rate |
2% per month |
Projected Cycle Life ( 25℃) |
20,000 times |
Round Trip Efficiency*1 |
96% |
Recommended Depth of Discharge |
≤90% |
Maximum Depth of Discharge |
100% |
Cooling Method |
Natural |
Shell Material |
Metal & ABS plastic |
Monitoring Data |
System voltage,current, temperature,SOC,SOH,cycle,cell`s voltage |
Weight |
20kg |
Dimensions(WxDxH) |
347x224x200mm |
Mount Options |
Wall/ floor |
Compatible Protocol: CAN, RS485
Company Feature
• Founded in our company has been engaged in the industry for and now has accumulated rich industry experience.
• has an elite team of professional talents with great overall strength, which lays a solid foundation to enhance product quality.
• gain a relatively large market share in China. They are also exported to Africa, Southeast Asia, and other countries and regions.
• is located in a place with traffic convenience, which is conducive for both small and large purchase.
Please feel free to contact at any time.
