Hotcapacitor Power Bank GTEM-96V20K-B Brand

Company Advantages

· capacitor power bank is created in line with the principle of 'Quality, Design, and Functions'.

· The performance of the product has been greatly optimized by our dedicated technical team.

· The product is suitable for various applications and is now widely used in the market.

Product Parameters

General Characteristics

Mechanical Specifications

Part Number	GTEM-96V20k-B
Energy storage	20kWh
Nominal Voltage	96Vdc
Nominal Capacity	210Ah
Maximum Charge Voltage	109.2Vdc
Discharge Cut-off Voltage	78Vdc
ESR/AC @1KHz 50% SOC	<150mΩ
Max. Continuous Charge Current	100A
Max. Continuous Discharge Current	500A
Absolute Peak Current 10s	600A
Discharge Temperature	-20℃~+60℃
Charge Temperature	0℃~+55℃
Cooling Method	Natural cooling
Operating Humidity	0~90% RH Non-condensing
Cells Self-discharge Rate	2% per month
Recommended Depth of Discharge	≤90%
Maximum Depth of Discharge	100%
Shell Material	Metal & ABS plastic
Monitoring Data	System voltage,current, temperature,SOC,SOH,cycle, cell’s voltage
Indicator light display	Capacity %
Environmental Protection	IP67
Storage Conditions	-20℃~+40℃ 25% ~ 95%RH SOC>30%，one full charge needed per two months

Weight	190kg
Dimensions(WxDxH)	810x550x500(mm)
Mount Options	On floor

Certificate&Compatible Protocol

Compatible Protocol: CAN, RS485

1 (10)

2 (9)

3 (7)

4 (7)

5 (8)

6 (11)

7 (6)

Download

GTEM-48V 7.4KWh Capess Datasheet

Company Features

· has been a notable manufacturer of capacitor power bank both in the domestic and international market and we enjoy a good reputation in the industry.

· The factory has been adhering to a strict quality management system. From materials purchase to the last stage of production, we make sure that products strictly meet the related national standards stipulated for this industry. The factory is equipped with a full set of modern advanced manufacturing facilities. These facilities have given great support for production, no matter in the aspects of guaranteeing product quality or the overall production efficiency.

· We conserve water across a wide range of actions extending from recycling water and installing new technologies to upgrading water treatment plants. Inquire!

Application of the Product

capacitor power bank of can be widely used in various fields.

insists on providing customers with comprehensive solutions based on their actual needs, so as to help them achieve long-term success.

Product Comparison

Compared with the same kind of products in the industry, capacitor power bank has the following highlights due to the better technical capability.
