Hothousehold Solar Battery Cost 29Vdc Brand

Product details of the household solar battery cost

Quick Detail

The raw materials of household solar battery cost are procured from our trusted vendors. The product is superior to its competitors in terms of quality, performance, durability, etc. With the support of strong service team, can produce high-quality household solar battery cost without nothing more to worry.

Product Description

Compared with the same kind of products in the industry, household solar battery cost has the following highlights due to the better technical capability.

Product Parameters

General Characteristics

Mechanical Specifications

Part Number	GTEM-24V1000-E
Energy storage	1.0kWh
Nominal Voltage	24Vdc
Maximum Charge Voltage	29Vdc
Discharge Cut-off Voltage	20Vdc
ESR/AC @1KHz 50% SOC	<15mΩ
Max. Continuous Charge Current	50A
Max. Continuous Discharge Current	50A
Peak Current	100A
Cooling Method	Natural
Cells Self-discharge Rate	2% per month
Projected Cycle Life ( 25℃)	20,000 times
Recommended Depth of Discharge	≤90%
Maximum Depth of Discharge	100%
Shell Material	Metal & ABS plastic
Monitoring Data	SOC,voltage,current, temperature
Series Connection	Not allowed
Parallel Connection	Up to 10sets
Series-Parallel Connection	Not allowed

Weight	8.5kg
Dimensions(WxDxH)	242x65x173(mm)
Mount Options	On floor

Certificate&Compatible Protocol

Compatible Protocol: CAN, RS485

1 (10)

2 (9)

3 (7)

4 (7)

5 (8)

6 (11)

7 (6)

Download

GTEM-48V 7.4KWh Capess Datasheet

Company Information

After years of stable manufacturing development, has been a backbone enterprise in the household solar battery cost industry. Our company has set up a sales team. As skilled problem solvers, the salesmen in this team can interact well with diverse populations and business partners. We have defined our business philosophy - We aim to provide the best outcome for our customers, in terms of products and services.
If you want to know more details of our products, please contact us. We are looking forward to cooperating with you!
