Made Deep Cycle Marine Battery Design for Sea Water

Product details of the deep cycle marine battery

Quick Overview

High-efficiency production: deep cycle marine battery is well manufactured. Every detail of this product is paid close attention and it is brought out with the fine quality and performance. The product has internationally certified quality and long service life. The product has a wide market due to its great economic benefits and practical application.

Product Introduction

will show you product's specific details below.

Product Parameters

General Characteristics

Mechanical Specifications

Part Number	GTEM-48V15K-W
Energy storage	15.2kWh
Nominal Voltage	48Vdc
Maximum Charge Voltage	58.8Vdc
Discharge Cut-off Voltage	39.2Vdc
ESR/AC @1KHz 50% SOC	<6mΩ
Max. Continuous Charge Current	200A
Max. Continuous Discharge Current	200A
Power/Energy	0.347
Cells Self-discharge Rate	2% per month
Projected Cycle Life ( 25℃)	10,000 times
Round Trip Efficiency*1	98%
Recommended Depth of Discharge	≤90%
Maximum Depth of Discharge	100%
Cooling Method	Natural
Shell Material	Metal & ABS plastic
Parallel Connection	Up to 5 sets
Monitoring Data	System voltage,current, temperature,SOC,SOH,cycle,cell`s voltage

Weight	90kg
Dimensions(WxDxH)	700x845x194(mm)
Mount Options	Wall/ floor

Certificate Options

1 (10)

2 (9)

3 (7)

4 (7)

5 (8)

6 (11)

7 (6)

Company Information

is mainly engaged in manufacturing all kinds of deep cycle marine battery. We have strength in human resources, especially in the R&D department. Our R&D members have deep expertise and creativity to create new products that are capitalized on trends or market niches. We are meeting our environmental responsibilities. We search for new ways to optimize our production processes by greatly reducing waste and energy consumption.
Our company is committed to providing professional and quality products with affordable prices for customers. Welcome customers in need to contact us, and look forward to establishing a mutually beneficial relationship with you!
