Company Advantages
· The raw material of use of capacitor bank undergoes a rigorous selection procedure.
· It is in high accordance with the first-class quality inspection standards.
· opens the market with high quality and low price.
Part Number |
GTSM-16V-500FUS |
Nominal capacitance |
500 F |
Capacitance tolerance |
+20% / -0%
|
Rated voltage |
16V |
Maximum absolute voltage |
17V |
Maximum series voltage |
750V |
ESR, DC |
1.8mΩ |
Maximum continuous current (ΔT=40℃) |
100 A |
Maximum peak current, 1 sec. |
2,275 A |
Maximum leakage current (after 72hrs @ 25℃) |
5.2 mA |
Operating temperature range(Cell case temperature) |
-40℃ to +65℃ |
Storage temperature range(Storage uncharged) |
-40℃ to +70℃ |
Power terminals |
M8/M10 |
Recommended torque - terminal |
20/30 Nm |
Vibration specification |
GB-T 11287-2000 |
Shock specification |
GBT 14537-1993 |
Environmental protection |
IP65 |
Weight |
5.7 kg |
Internal temperature sensor |
NTC Thermistor |
Cell voltage monitoring |
Overvoltage Alarm |
Usable power density (Pd) |
3,590 W/kg |
Compatible Protocol: CAN, RS485
Company Features
· Since its establishment, has been a professional manufacturer in the industry after years of accumulated experience in developing and designing use of capacitor bank.
· Solid technical foundation is the key for to greatly improve quality of use of capacitor bank. has set up professional R&D base to provide technical support. is technologically advanced, which makes it stands at forefront in the field of use of capacitor bank.
· We continuously improve the corporate environmental management system. We attach great importance to water conservation, and actively promote water-saving equipment and water-saving concepts.
Product Details
The use of capacitor bank we produce are able to stand up to the details.
Application of the Product
The use of capacitor bank produced by our company is widely recognized by customers and widely used in field.
has established a professional technical team. They can provide customers with targeted processes and solutions. Based on this, the problems of customers can be better solved.
Welcome, Shanghai Green Tech (GTCAP) is a supercapacitor battery manufacturer and energy storage solutions provider,
offering OEM, ODM and customized energy storage solutions for customers.
