New Deep Cycle Marine Battery 100ah Deep Cycle Marine Battery 100ah Company 1
New Deep Cycle Marine Battery 100ah Deep Cycle Marine Battery 100ah Company 1

New Deep Cycle Marine Battery 100ah Deep Cycle Marine Battery 100ah Company

Part Number:
GTEM-400V14.4K-R
Nominal Voltage:
400Vdc
Maximum Charge Voltage:
453.6Vdc
Max. Continuous Charge Current:
30A
Energy storage:
14.4kWh
Inquiry

Product details of the deep cycle marine battery 100ah


Quick Overview

deep cycle marine battery 100ah is manufactured by dedicated workers who pay close attention to the production process. This product is not only powerful, but also durable and has a longer service life than other competing products. has gained outstanding reputation amongst the vast clients.


Product Description

deep cycle marine battery 100ah has better quality than other products in the industry, which is specifically shown in the following aspects.

Product Parameters
General Characteristics
Mechanical Specifications

Part Number

GTEM-400V14.4K-R



Energy storage

14.4kWh



Nominal Voltage

400Vdc



Maximum Charge Voltage

453.6Vdc



Discharge Cut-off Voltage

291.6Vdc



ESR/AC @1KHz 50% SOC

<200mΩ



Max. Continuous Charge Current

30A



Max. Continuous Discharge Current

30A



Round Trip Efficiency*1

96%



Projected Cycle Life ( 25℃)

20,000 times



Recommended Depth of Discharge

≤90%



Maximum Depth of Discharge

100%



Cooling Method

Natural



Shell Material

Metal & ABS plastic



Monitoring Data

System voltage,current, temperature,

SOC,SOH,cycle,cell’s voltage



Parallel connection optional

Up to 4sets (400V 60KWh)



Communication

CAN, RS485



Weight

165kg±5kg

Dimensions(WxDxH)

520x732x653(mm)

Mount Options

On floor

Certificate Options
1 (10)
1 (10)
2 (9)
2 (9)
3 (7)
3 (7)
4 (7)
4 (7)
5 (8)
5 (8)
6 (11)
6 (11)
7 (6)
7 (6)


Company Introduction

is influential in the industry of deep cycle marine battery 100ah. With years of technical experience in the deep cycle marine battery 100ah industry and customer service awareness, we have won more trust from customers all over the world. Compared to previous years, we have established more business cooperations with clients. We accept individual and corporate responsibility for our actions, working together to deliver quality services and to promote the best interest of our clients.
If you need to buy our products, welcome to contact us!

Contact us
we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
