OEM Industrial Capacitor Bank 150A

Nominal Voltage:
72Vdc
Maximum Charge Voltage:
84Vdc
Max. Continuous Discharge Current:
150A
Max. Continuous Charge Current:
150A
Energy storage:
18.72kWh
Inquiry

Product details of the industrial capacitor bank


Product Information

industrial capacitor bank is designed by renowned designers in the field. The product is rather durable to use, can hold up over time. Advanced equipment in ensure the bulk production of industrial capacitor bank to raise the efficiency.

Product Parameters
General Characteristics
Mechanical Specifications

Part Number

GTEM-72V18720-F

Energy storage

18.72kWh

Nominal Voltage

72Vdc

Maximum Charge Voltage

84Vdc

Discharge Cut-off Voltage

56Vdc

ESR/AC @1KHz 50% SOC

<50mΩ

Max. Continuous Charge Current

150A

Max. Continuous Discharge Current

150A

Projected Cycle Life ( 25℃)

20,000 times

Recommended Depth of Discharge

≤90%

Maximum Depth of Discharge

100%

Charge Temperature

0℃~+55℃

Discharge Temperature

-20℃~+60℃

Cooling Method

Natural

Shell Material

Metal & ABS plastic

Parallel Connection

Recommend within 10sets

Monitoring Data

SOC,voltage, module

Weight

230kg

Dimensions(WxDxH)

740x540x320(mm)

Mount Options

Wall / floor

Certificate&Compatible Protocol

Compatible Protocol: CAN, RS485
