On Sale Battery Pack for Household Series for Home

Product details of the battery pack for household

Product Information

battery pack for household is made of the first-rate materials. It has been tested by the harsh international first-class inspection standards. has strong research and development capabilities for battery pack for household.

Product Parameters

General Characteristics

Mechanical Specifications

Part Number	GTEM-24V5000-F
Energy storage	5.0kWh
Nominal Voltage	24Vdc
Maximum Charge Voltage	29Vdc
Discharge Cut-off Voltage	20Vdc
ESR/AC @1KHz 50% SOC	<10mΩ
Max. Continuous Charge Current	150A
Max. Continuous Discharge Current	150A
Projected Cycle Life ( 25℃)	20,000 times
Recommended Depth of Discharge	≤90%
Maximum Depth of Discharge	100%
Charge Temperature	0℃~+55℃
Discharge Temperature	-20℃~+60℃
Cooling Method	Natural
Shell Material	Metal & ABS plastic
Parallel Connection	Recommend within 10sets
Monitoring Data	SOC,voltage, module

Weight	190kg
Dimensions(WxDxH)	645x565x245(mm)
Mount Options	Wall / floor

Certificate&Compatible Protocol

Compatible Protocol: CAN, RS485

1 (10)

2 (9)

3 (7)

4 (7)

5 (8)

6 (11)

7 (6)

Download

GTEM-48V 7.4KWh Capess Datasheet

Company Advantage

• has established sales outlets in major cities in China. The products are also exported to Europe, America, Southeast Asia, and other regions.
• Founded in our company has always put the quality of products and customer satisfaction in the first place. So, we can gain the favor of consumers.
• is committed to providing customers with thoughtful, comprehensive and diversified services. And we strive to gain mutual benefit by cooperating with customers.
We are responsible for the production of high-quality products, please contact us to order if in need.
