On Sale Graphene Battery Manufacturer Graphene Battery Manufacturer Company

Company Advantages

· The design style of graphene battery manufacturer expresses the details thoroughly.

· The product is well-received in the market for its long service life and stable performance.

· will continue to upgrade its management system and accelerate the process of building the brand.

Product Parameters

General Characteristics

Mechanical Specifications

Part Number	GTEM-48V3600-G
Energy storage	3.62kWh
Nominal Voltage	48Vdc
Maximum Charge Voltage	58.8Vdc
Discharge Cut-off Voltage	37Vdc
ESR/AC @1KHz 50% SOC	<20mΩ
Max. Continuous Charge Current	200A
Max. Continuous Discharge Current	200A
Cut-off Current (charging)	4A
Absolute Peak Current 3s	300A
Discharge Temperature	-20℃~+60℃
Charge Temperature	0℃~+55℃
Cooling Method	Natural cooling
Operating Humidity	0~90% RH Non-condensing
Cells Self-discharge Rate	2% per month
Projected Cycle Life ( 25℃)	20,000 times
Recommended Depth of Discharge	≤90%
Maximum Depth of Discharge	100%
Shell Material	Metal & ABS plastic
Monitoring Data	System voltage,current, temperature,SOC,SOH,cycle, cell’s voltage
Indicator light display	Capacity %
Environmental Protection	IP65
Storage Conditions	-20℃~+40℃ 25% ~ 95%RH SOC>30%，one full charge needed per two months

Weight	55kg
Dimensions(WxDxH)	720x355x252(mm)
Mount Options	On floor

Certificate&Compatible Protocol

Compatible Protocol: CAN, RS485

1 (10)

2 (9)

3 (7)

4 (7)

5 (8)

6 (11)

7 (6)

Download

GTEM-48V 7.4KWh Capess Datasheet

Company Features

· With years of hard work and accumulation, has gained higher status for its

· We have adopted an advanced production control system. With the help of this advanced control system, we can effectively manage our orders in real-time and optimize our production times.

· Undertaking corporate social responsibility has become increasingly important to our company. We attach great importance to human rights. For example, we are determined to boycott any gender or ethnics discrimination by empowering them with equal rights.

Product Details

We pursue perfection in every detail of the graphene battery manufacturer we produce. And our products represent the excellent quality.
