Panel Capacitor Bank 55kg Brand 48Vdc

Company Advantages

· panel capacitor bank is made in tune with international production norms.

· The product has undergone strict tests according to international quality standards.

· The successful establishment of sales network better guaranteed the development of

Product Parameters

General Characteristics

Mechanical Specifications

Part Number	GTEM-48V3600-G
Energy storage	3.62kWh
Nominal Voltage	48Vdc
Maximum Charge Voltage	58.8Vdc
Discharge Cut-off Voltage	37Vdc
ESR/AC @1KHz 50% SOC	<20mΩ
Max. Continuous Charge Current	200A
Max. Continuous Discharge Current	200A
Cut-off Current (charging)	4A
Absolute Peak Current 3s	300A
Discharge Temperature	-20℃~+60℃
Charge Temperature	0℃~+55℃
Cooling Method	Natural cooling
Operating Humidity	0~90% RH Non-condensing
Cells Self-discharge Rate	2% per month
Projected Cycle Life ( 25℃)	20,000 times
Recommended Depth of Discharge	≤90%
Maximum Depth of Discharge	100%
Shell Material	Metal & ABS plastic
Monitoring Data	System voltage,current, temperature,SOC,SOH,cycle, cell’s voltage
Indicator light display	Capacity %
Environmental Protection	IP65
Storage Conditions	-20℃~+40℃ 25% ~ 95%RH SOC>30%，one full charge needed per two months

Weight	55kg
Dimensions(WxDxH)	720x355x252(mm)
Mount Options	On floor

Certificate&Compatible Protocol

Compatible Protocol: CAN, RS485

1 (10)

2 (9)

3 (7)

4 (7)

5 (8)

6 (11)

7 (6)

Download

GTEM-48V 7.4KWh Capess Datasheet

Company Features

· mainly produces high quality panel capacitor bank with stable supply.

· has a complete panel capacitor bank production laboratory, which can produce more elaborate products. panel capacitor bank enjoys good quality performance and wins more favors from customers.

· We are committed to conducting business in a responsible and suitable manner. We have established efficient processes, clear responsibilities to implement sustainability in our organization and along our supply chain.

Product Details

The processing of panel capacitor bank is carried out with the most advanced technology in the industry to ensure that the following details are better.
