Power Storage Solutions 417x190x176mmcustomized

Product Parameters

General Characteristics

Mechanical Specifications

Part Number	GTSM-48V165FUS
Nominal capacitance	125 F
Capacitance tolerance	-10%~~+20%
Rated voltage	48V
Maximum absolute voltage	51V
ESR, DC	5 mΩ
Maximum continuous current (ΔT=40℃)	100 A
Maximum peak current, 1 sec.	2,275 A
Maximum leakage current (after 72hrs @ 25℃)	5.2 mA
Operating temperature range (Cell case temperature)	-40℃ to +65℃
Storage temperature range(Storage uncharged)	-40℃ to +70℃
Power terminals	M8 Screw Hole
Negative Terminal	M10 Screw Hole
Recommended torque - terminal	20/30 Nm
Vibration specification	SAE J2380 ISO16750-2, T14
Shock specification	SAE J2464
Colling	Natural Convection

Weight	20kg
Environmental protection	IP65
Internal temperature sensor	NTC Thermistor
Cell voltage monitoring	Overvoltage Alarm

Certificate&Compatible Protocol

Compatible Protocol: CAN, RS485

1 (10)

2 (9)

3 (7)

4 (7)

5 (8)

6 (11)

7 (6)

Download

GTEM-48V 7.4KWh Capess Datasheet

Company Advantages

· power storage solutions represents the finest workmanship in the market as it is manufactured using the leading technology.

· The value of product are shown with strong reliability and excellent practicality.

· Through our unremitting efforts, the product is now well-received in the marketplace and has a great commercial value.

Company Features

· gives zest and enthusiasm in designing and manufacturing power storage solutions. We provide the best product and the dedicated service our customers deserve.

· Our technical team are very professional and responsible to ensure best quality of power storage solutions.

· With the goal of becoming stronger in the future, aims to provide the best power storage solutions and service for customers. Call!

Application of the Product

The power storage solutions produced by is widely used.

In addition to creating excellent is also able to provide comprehensive and reasonable solutions for customers.
