Professional Battery Energy Storage System 210Ah with Good Price for Sea Water

Product details of the battery energy storage system

Product Information

Innovative design concept: the design concept of battery energy storage system is put forward and completed by a team of designers who are full of innovative design ideas. These ideas not only meet the industrial standards but cater to the market demands. With accuracy and safety, the product is qualified to use. Providing the most reliable battery energy storage system for customers always will help to stand out in the market.

Product Parameters

General Characteristics

Mechanical Specifications

Part Number	GTEF-716V100K-R
Energy storage	150.5kWh
Nominal Voltage	716.8Vdc
Maximum Charge Voltage	806.4Vd.c (Recommended high voltage limit:784V)
Discharge Cut-off Voltage	604.8Vd.c (Recommended low voltage limit: 627.2V)
ESR/AC @1KHz 50% SOC	<150mΩ
Max. Continuous Charge Current	150A
Max. Continuous Discharge Current	150A
Operating Humidity	0~90% RH Non-condensing
Cells Self-discharge Rate	2% per month
Projected Cycle Life ( 25℃)	10,000 times(70%EOL)
Recommended Depth of Discharge	≤ 90%
Maximum Depth of Discharge	100%
Monitoring Data	System voltage,current, temperature,SOC,SOH,cycle,cell’s voltage
Terminal	Large power energy storage terminals
Environmental Protection	IP20 Indoor
Shell Material	Metal
Parallel Connection	No limited ( add controller box )
communication	CAN, RS485, LAN

Weight	1560kg
Dimensions(WxDxH)	801x832x2166(mm)
Mount Options	On floor

Certificate Options

1 (10)

2 (9)

3 (7)

4 (7)

5 (8)

6 (11)

7 (6)

Company Advantage

• formally established in has changed the traditional marketing model into a new network marketing model after years of diligent research. We attract the attention of people from all walks of life, and receive support to successfully break the barriers between contemporary business and traditional business. Now, our company becomes an outstanding enterprise in the industry.
• Our series of products sell well in many parts of the country. And they are exported to the EU, Southeast Asia, the Americas and other regions.
• To meet the diversified needs of domestic and foreign customers, our company has domestic first-class R&D talents and a large-scale production team.
Contact now and you can get free samples!
