Part Number	GTEG-23V4180-F
Energy storage	4.18kWh
Nominal Capacity	182Ah
Nominal Voltage	23Vdc
Absolute Maximum Voltage	28Vdc
Cut-off Voltage (discharging)	18Vdc
Configuration	10S13P
Pack resistance	< 10 mΩ
Continuous Charge Current	150A
Continuous Discharge Current	150A
Peak Discharge Current	300A
Recommended Depth of Discharge	90%
Maximum Depth of Discharge	100%
Cooling	Natural cooling
Ingress Protection	IP55
Storage Humidity	25% ~ 95%RH
Operating Humidity	0 – 90% RH
Storage Temperature	-20℃~40 ℃

Weight	225kg
Dimensions(WxDxH)	650195600mm
Mount Options	Wall/ floor

Certificate&Compatible Protocol

Compatible Protocol: CAN, RS485

1 (10)

2 (9)

3 (7)

4 (7)

5 (8)

6 (11)

7 (6)

Download

GTEM-48V 7.4KWh Capess Datasheet

Company Advantages

· solar battery energy storage is manufactured using quality raw materials and state-of-the-art technology in tune with the set of industrial principles.

· solar battery energy storage can deeply convince the client of its merits.

· solar battery energy storage is a highly marketable commodity with high quality.

Company Features

· As a big manufacturer of solar battery energy storage, has won its competitiveness in its industry.

· Our finest solar battery energy storage is produced by our advanced machines.

· We emphasize environmental responsibility of our factory. We offer products designed to replace the environmentally destructive ones that elevate the carbon footprint.

Application of the Product

solar battery energy storage has a wide range of applications.

Our solutions are specially set up to the customer's actual situation and needs to ensure that the solutions provided to the customer are effective.
