Standardcapacitor Bank 1560kg Brand

Product details of the capacitor bank

Product Overview

capacitor bank is designed using top class material and advanced tools & equipment under the guidance of highly skilled designers. Our quality experts test this product on different parameters, so as to maintain the quality. capacitor bank is widely used in the industry. The product is attracting more and more market attention and will be more used in the future.

Product Introduction

Compared with other products in the same industry, capacitor bank has the following characteristics.

Product Parameters

General Characteristics

Mechanical Specifications

Part Number	GTEF-716V100K-R
Energy storage	150.5kWh
Nominal Voltage	716.8Vdc
Maximum Charge Voltage	806.4Vd.c (Recommended high voltage limit:784V)
Discharge Cut-off Voltage	604.8Vd.c (Recommended low voltage limit: 627.2V)
ESR/AC @1KHz 50% SOC	<150mΩ
Max. Continuous Charge Current	150A
Max. Continuous Discharge Current	150A
Operating Humidity	0~90% RH Non-condensing
Cells Self-discharge Rate	2% per month
Projected Cycle Life ( 25℃)	10,000 times(70%EOL)
Recommended Depth of Discharge	≤ 90%
Maximum Depth of Discharge	100%
Monitoring Data	System voltage,current, temperature,SOC,SOH,cycle,cell’s voltage
Terminal	Large power energy storage terminals
Environmental Protection	IP20 Indoor
Shell Material	Metal
Parallel Connection	No limited ( add controller box )
communication	CAN, RS485, LAN

Weight	1560kg
Dimensions(WxDxH)	801x832x2166(mm)
Mount Options	On floor

Certificate Options

1 (10)

2 (9)

3 (7)

4 (7)

5 (8)

6 (11)

7 (6)
