Supercapacitor Bank 200A Wholesale - 1
Supercapacitor Bank 200A Wholesale - 2
Supercapacitor Bank 200A Wholesale - 1
Supercapacitor Bank 200A Wholesale - 2

Supercapacitor Bank 200A Wholesale -

Part Number:
GTEM-48V4500-G
Nominal Voltage:
48Vdc
Max. Continuous Discharge Current:
200A
Max. Continuous Charge Current:
200A
Dimensions(WxDxH):
720x355x252mm
Inquiry
Send your inquiry

Product details of the supercapacitor bank


Product Information

supercapacitor bank is designed by a professional team of designers who are strictly hired by our company. The product will not be delivered until it is assured to be pf the high quality. improves the quality of after-sales service to determine the market.

Product Parameters
General Characteristics
Mechanical Specifications

Part Number

GTEM-48V4500-G

Energy storage

4.5kWh

Nominal Voltage

48Vdc

Nominal Capacity

130Ah

Maximum Charge Voltage

58.8Vdc

Discharge Cut-off Voltage

40Vdc

ESR/AC @1KHz 50% SOC

<30mΩ

Max. Continuous Charge Current

200A

Max. Continuous Discharge Current

200A

Absolute Peak Current 3s

400A

Discharge Temperature

-20℃~+60℃

Charge Temperature

0℃~+55℃

Cooling Method

Natural cooling

Operating Humidity

0~90% RH Non-condensing

Cells Self-discharge Rate

2% per month

Projected Cycle Life ( 25℃)

20,000 times

Recommended Depth of Discharge

≤90%

Maximum Depth of Discharge

100%

Shell Material

Metal & ABS plastic

Monitoring Data

Module voltage,SOC

Indicator light display

Capacity %

Environmental Protection

IP65

Storage Conditions

-20℃~+40℃

25% ~ 95%RH

SOC>30%,one full charge needed per two months

Weight

55kg

Dimensions(WxDxH)

720x355x252(mm)

Mount Options

On floor

Certificate&Compatible Protocol

Compatible Protocol: CAN, RS485
