Top Sellingpanel Capacitor Bank Manufacture

Weight:
8.5kg
Max. Continuous Discharge Current:
50A
Energy storage:
1.0kWh
Discharge Cut-off Voltage:
20Vdc
Dimensions(WxDxH):
242x65x173mm
Inquiry

Product Parameters
General Characteristics
Mechanical Specifications

Part Number

GTEM-24V1000-E

Energy storage

1.0kWh

Nominal Voltage

24Vdc

Maximum Charge Voltage

29Vdc

Discharge Cut-off Voltage

20Vdc

ESR/AC @1KHz 50% SOC

<15mΩ

Max. Continuous Charge Current

50A

Max. Continuous Discharge Current

50A

Peak Current

100A

Cooling Method

Natural

Cells Self-discharge Rate

2% per month

Projected Cycle Life ( 25℃)

20,000 times

Recommended Depth of Discharge

≤90%

Maximum Depth of Discharge

100%

Shell Material

Metal & ABS plastic

Monitoring Data

SOC,voltage,current, temperature

Series Connection

Not allowed

Parallel Connection

Up to 10sets

Series-Parallel Connection

Not allowed

Weight

8.5kg

Dimensions(WxDxH)

242x65x173(mm)

Mount Options

On floor

Certificate&Compatible Protocol

Compatible Protocol: CAN, RS485

1 (10)
1 (10)
2 (9)
2 (9)
3 (7)
3 (7)
4 (7)
4 (7)
5 (8)
5 (8)
6 (11)
6 (11)
7 (6)
7 (6)

Download


Company Advantages

· panel capacitor bank is fabricated using the top-grade raw material and sophisticated production technology.

· Every aspect of the product is strictly tested to meet international quality standards.

· is ceaselessly developing new products to satisfy customers' new needs.


Company Features

· has become one of the most competitive manufacturers of panel capacitor bank. We are remarked as a reliable manufacturer and supplier.

· Technical development strength and rich production experience have become core competitiveness.

· will stick to using the first-class technology, first-class management, first-class products and first-class service to return customer. Get an offer!


Application of the Product

panel capacitor bank, one of main products, is deeply favored by customers. With wide application, it can be applied to different industries and fields.

always provides customers with reasonable and efficient one-stop solutions based on the professional attitude.

Contact us
we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
