Types of Capacitor Bank 42Vdc Brand 58Vdc

Product Parameters

General Characteristics

Mechanical Specifications

Part Number	GTEM-48V8500-G
Energy storage	8.5kWh
Nominal Voltage	48Vdc
Maximum Charge Voltage	58Vdc
Discharge Cut-off Voltage	42Vdc
ESR/AC @1KHz 50% SOC	<15mΩ
Max. Continuous Charge Current	200A
Max. Continuous Discharge Current	200A
Absolute Peak Current 10s	300A
Discharge Temperature	-20℃~+60℃
Charge Temperature	0℃~+55℃
Cooling Method	Natural cooling
Operating Humidity	0~90% RH Non-condensing
Cells Self-discharge Rate	2% per month
Projected Cycle Life ( 25℃)	20,000 times
Recommended Depth of Discharge	≤90%
Maximum Depth of Discharge	100%
Shell Material	Metal & ABS plastic
Monitoring Data	Module voltage,SOC
Indicator light display	Capacity %
Environmental Protection	IP65
Storage Conditions	-20℃~+40℃ 25% ~ 95%RH SOC>30%，one full charge needed per two months

Weight	75kg
Dimensions(WxDxH)	950x400x252(mm)
Mount Options	On floor

Certificate&Compatible Protocol

Compatible Protocol: CAN, RS485

1 (10)

2 (9)

3 (7)

4 (7)

5 (8)

6 (11)

7 (6)

Download

GTEM-48V 7.4KWh Capess Datasheet

Company Advantages

· The types of capacitor bank unique in its design are very famous.

· The operation of our types of capacitor bank is very simple, even inexperienced worker can learn it in short time. .

· thinks quality of is the most important and can guarantee for quality.

Company Features

· has been considered as a competitive manufacturer of types of capacitor bank, with years of expertise in design and production.

· We have a team of professionals in charge of customer service. They are qualified in communication and language skills. Besides, they can always offer clients valuable information regards to product types, functions, prices, delivery, customization, after-sales services, etc.

· global manufacturing, sales and marketing personnel are keenly focused on meeting our customer’s product needs. Check it!

Application of the Product

types of capacitor bank is widely applicable in the industry.

In addition to high-quality products, also provides effective solutions based on the actual conditions and the needs of different customers.
