Use of Capacitor Bank Brand ODM

Product Parameters

General Characteristics

Mechanical Specifications

Part Number	GTSM-16V-500FUS
Nominal capacitance	500 F
Capacitance tolerance	+20% / -0%
Rated voltage	16V
Maximum absolute voltage	17V
Maximum series voltage	750V
ESR, DC	1.8mΩ
Maximum continuous current (ΔT=40℃)	100 A
Maximum peak current, 1 sec.	2,275 A
Maximum leakage current (after 72hrs @ 25℃)	5.2 mA
Operating temperature range(Cell case temperature)	-40℃ to +65℃
Storage temperature range(Storage uncharged)	-40℃ to +70℃
Power terminals	M8/M10
Recommended torque - terminal	20/30 Nm
Vibration specification	GB-T 11287-2000
Shock specification	GBT 14537-1993
Environmental protection	IP65

Weight	5.7 kg
Internal temperature sensor	NTC Thermistor
Cell voltage monitoring	Overvoltage Alarm
Usable power density (Pd)	3,590 W/kg

Certificate&Compatible Protocol

Compatible Protocol: CAN, RS485

1 (10)

2 (9)

3 (7)

4 (7)

5 (8)

6 (11)

7 (6)

Download

GTEM-48V 7.4KWh Capess Datasheet

Company Advantages

· After long-time R&D effort, use of capacitor bank is given a reasonable, practical, and aesthetic design.

· Fewer defects or field failures result in lower service costs.

· The product is popular among old and new customer and boasts a promising market application prospect.

Company Features

· is a choice for professional use of capacitor bank worldwide. We develop, produce and distribute products for customers worldwide.

· Our professional personnel engaged in manufacturing is the strength of our business. They are responsible for designing, manufacturing, testing, and quality control for years.

· will adhere to the firm belief of becoming an international use of capacitor bank exporter. Get info!

Application of the Product

use of capacitor bank is one of the main products of With wide application, our product can be applied to different industries and fields. And it is deeply loved and favored by customers.

With a focus on customers, analyzes problems from the perspective of customers and provides comprehensive, professional and excellent solutions.
