Use of Capacitor Bank Company - GTEF-716V150kWh-R

Company Advantages

· adopts people-centric approach to use of capacitor bank product design.

· The product is absolutely quality-assured as it has been thoroughly tested on every stage of the production process by our quality controllers as per the set industry norms.

· has secured the quality of use of capacitor bank before the loading.

Product Parameters

General Characteristics

Mechanical Specifications

Part Number	GTEF-716V100K-R
Energy storage	150.5kWh
Nominal Voltage	716.8Vdc
Maximum Charge Voltage	806.4Vd.c (Recommended high voltage limit:784V)
Discharge Cut-off Voltage	604.8Vd.c (Recommended low voltage limit: 627.2V)
ESR/AC @1KHz 50% SOC	<150mΩ
Max. Continuous Charge Current	150A
Max. Continuous Discharge Current	150A
Operating Humidity	0~90% RH Non-condensing
Cells Self-discharge Rate	2% per month
Projected Cycle Life ( 25℃)	10,000 times(70%EOL)
Recommended Depth of Discharge	≤ 90%
Maximum Depth of Discharge	100%
Monitoring Data	System voltage,current, temperature,SOC,SOH,cycle,cell’s voltage
Terminal	Large power energy storage terminals
Environmental Protection	IP20 Indoor
Shell Material	Metal
Parallel Connection	No limited ( add controller box )
communication	CAN, RS485, LAN

Weight	1560kg
Dimensions(WxDxH)	801x832x2166(mm)
Mount Options	On floor

Certificate Options

1 (10)

2 (9)

3 (7)

4 (7)

5 (8)

6 (11)

7 (6)

Company Features

· becomes competitive for the well-made use of capacitor bank. We have been devoted ourselves to R&D and manufacture for years.

· Each part of use of capacitor bank will be checked by our professional QC department.

· We take care of each step in the production process to make sure every stage meets regulations for protecting the environment.

Product Comparison

39;s technical level is higher than its peers. Compared with peer products, the use of capacitor bank produced by us has the following highlights.
