Wholesalehousehold Battery Pack Household Battery Pack Company

Company Advantages

· household battery pack is made as per the international quality standards.

· A strict quality assurance system has been established to ensure the quality of the product.

· provides marketing, sales and after-sales service support for household battery pack product.

Product Parameters

General Characteristics

Mechanical Specifications

Part Number	GTEM-96V20k-B
Energy storage	20kWh
Nominal Voltage	96Vdc
Nominal Capacity	210Ah
Maximum Charge Voltage	109.2Vdc
Discharge Cut-off Voltage	78Vdc
ESR/AC @1KHz 50% SOC	<150mΩ
Max. Continuous Charge Current	100A
Max. Continuous Discharge Current	500A
Absolute Peak Current 10s	600A
Discharge Temperature	-20℃~+60℃
Charge Temperature	0℃~+55℃
Cooling Method	Natural cooling
Operating Humidity	0~90% RH Non-condensing
Cells Self-discharge Rate	2% per month
Recommended Depth of Discharge	≤90%
Maximum Depth of Discharge	100%
Shell Material	Metal & ABS plastic
Monitoring Data	System voltage,current, temperature,SOC,SOH,cycle, cell’s voltage
Indicator light display	Capacity %
Environmental Protection	IP67
Storage Conditions	-20℃~+40℃ 25% ~ 95%RH SOC>30%，one full charge needed per two months

Weight	190kg
Dimensions(WxDxH)	810x550x500(mm)
Mount Options	On floor

Certificate&Compatible Protocol

Compatible Protocol: CAN, RS485

1 (10)

2 (9)

3 (7)

4 (7)

5 (8)

6 (11)

7 (6)

Download

GTEM-48V 7.4KWh Capess Datasheet

Company Features

· Since our establishment, has developed and expanded as a competitive manufacturer of household battery pack through technological expertise.

· Our factory is placed in a potentially satisfactory location. It is easily accessible to the airports and ports within an hour. This helps minimize the unit cost of production and distribution for our company. Besides, our customers don't have to wait too much time for the goods. Being in the right factory location is a key ingredient in our business. This allows us to provide easy access to customers, workers, transportation, materials, and so on. And this will maximize opportunity while minimizing our costs and risks.

· Every member of has sincerity and enthusiasm to ensure the most convenient service to our valued clients. Check it!

Product Details

The details of household battery pack are shown for you at below.

Product Comparison

Compared with products in the industry, household battery pack has the outstanding advantages which are mainly reflected in the following aspects.
