Energy Storage Systems 48Vdc Wholesale -

Series:

EM Series

Nominal Voltage:

48Vdc

Max. Continuous Discharge Current:

200A

Discharge Cut-off Voltage:

37Vdc

Dimensions(WxDxH):

720x355x252mm

Product Parameters

General Characteristics

Mechanical Specifications

Part Number	GTEM-48V3600-G
Energy storage	3.62kWh
Nominal Voltage	48Vdc
Maximum Charge Voltage	58.8Vdc
Discharge Cut-off Voltage	37Vdc
ESR/AC @1KHz 50% SOC	<20mΩ
Max. Continuous Charge Current	200A
Max. Continuous Discharge Current	200A
Cut-off Current (charging)	4A
Absolute Peak Current 3s	300A
Discharge Temperature	-20℃~+60℃
Charge Temperature	0℃~+55℃
Cooling Method	Natural cooling
Operating Humidity	0~90% RH Non-condensing
Cells Self-discharge Rate	2% per month
Projected Cycle Life ( 25℃)	20,000 times
Recommended Depth of Discharge	≤90%
Maximum Depth of Discharge	100%
Shell Material	Metal & ABS plastic
Monitoring Data	System voltage,current, temperature,SOC,SOH,cycle, cell’s voltage
Indicator light display	Capacity %
Environmental Protection	IP65
Storage Conditions	-20℃~+40℃ 25% ~ 95%RH SOC>30%，one full charge needed per two months

Certificate&Compatible Protocol

Compatible Protocol: CAN, RS485

1 (10)

2 (9)

3 (7)

4 (7)

5 (8)

6 (11)

7 (6)

Download

Company Advantages

· energy storage systems is known for combining aesthetic functionality and innovation.

· It has reliable quality and stable performance.

· As per quality, energy storage systems is strictly tested by professional persons.

Company Features

· is a modern energy storage systems high-tech company integrating scientific research, development, production and sales.

· has established its own research and testing department to improve product quality.

· Over the years, has improved credibility, customer satisfaction, and revenue.

Application of the Product

energy storage systems can be applied to different industries, fields and scenarios.

With a focus on is dedicated to providing reasonable solutions for customers.
