Solar Home Batteries Brand 39.2Vdc Capwall Series

Product details of the solar home batteries

Product Introduction

The raw material used for the solar home batteries is procured from some of the reliable vendors. Good properties of solar home batteries are main advantages for solar home batteries. In line with the principle of serving customers, delivers fast, providing good quality and competitive price.

Product Parameters

General Characteristics

Mechanical Specifications

Part Number	GTEM-48V15K-W
Energy storage	15.2kWh
Nominal Voltage	48Vdc
Maximum Charge Voltage	58.8Vdc
Discharge Cut-off Voltage	39.2Vdc
ESR/AC @1KHz 50% SOC	<6mΩ
Max. Continuous Charge Current	200A
Max. Continuous Discharge Current	200A
Power/Energy	0.347
Cells Self-discharge Rate	2% per month
Projected Cycle Life ( 25℃)	10,000 times
Round Trip Efficiency*1	98%
Recommended Depth of Discharge	≤90%
Maximum Depth of Discharge	100%
Cooling Method	Natural
Shell Material	Metal & ABS plastic
Parallel Connection	Up to 5 sets
Monitoring Data	System voltage,current, temperature,SOC,SOH,cycle,cell`s voltage

Weight	90kg
Dimensions(WxDxH)	700x845x194(mm)
Mount Options	Wall/ floor

Certificate Options

1 (10)

2 (9)

3 (7)

4 (7)

5 (8)

6 (11)

7 (6)

Company Feature

• was established in Based on the accumulation of rich industry experience, the level of our production and processing is far more beyond the peers.
• goal is to sincerely provide consumers with quality products as well as professional and thoughtful services.
• has a professional team integrates management, R&D, production, inspection, marketing, and after-sales service. This lays a solid foundation for the development.
• Based on the domestic market, is actively exploring foreign markets.
If you want to know more detailed information, feel free to consult
