Wholesale Household Batteries for Solar Brand

Product details of the household batteries for solar

Product Information

attaches great importance to the design of household batteries for solar. The product meets international standards in all aspects, such as performance, durability, availability and more. regards quality as its life and establishes a perfect quality assurance system.

Product Parameters

General Characteristics

Mechanical Specifications

Part Number	GTEM-24V1000-E
Energy storage	1.0kWh
Nominal Voltage	24Vdc
Maximum Charge Voltage	29Vdc
Discharge Cut-off Voltage	20Vdc
ESR/AC @1KHz 50% SOC	<15mΩ
Max. Continuous Charge Current	50A
Max. Continuous Discharge Current	50A
Peak Current	100A
Cooling Method	Natural
Cells Self-discharge Rate	2% per month
Projected Cycle Life ( 25℃)	20,000 times
Recommended Depth of Discharge	≤90%
Maximum Depth of Discharge	100%
Shell Material	Metal & ABS plastic
Monitoring Data	SOC,voltage,current, temperature
Series Connection	Not allowed
Parallel Connection	Up to 10sets
Series-Parallel Connection	Not allowed

Weight	8.5kg
Dimensions(WxDxH)	242x65x173(mm)
Mount Options	On floor

Certificate&Compatible Protocol

Compatible Protocol: CAN, RS485

1 (10)

2 (9)

3 (7)

4 (7)

5 (8)

6 (11)

7 (6)

Download

GTEM-48V 7.4KWh Capess Datasheet

Company Feature

• are not only supplied to various regions in China, but also exported to different overseas countries and regions. And they are very popular and influential in the domestic and foreign market.
• With the convenient highway access around our company and the great geographic location, ourpan> is provided with convenient transportation.
• has a large number of outstanding professional talents, which lays a solid foundation for the development.
Hello, thanks for your attention to this site! If you are interested in products or services, you can contact us directly. We keep ourselves open to new partnerships.
